INCH-POUND
MIL-DTL-55302/71D
12 November 2004
SUPERSEDING
MIL-C-55302/71C (USAF)
17 October 1986
DETAIL SPECIFICATION SHEET
CONNECTORS, PRINTED CIRCUIT SUBASSEMBLY AND ACCESSORIES,
SOCKET RECEPTACLE, ELECTRICAL, POLARIZED
COMPOSITE CONTACT (.100 SPACING)
MIL-DTL-55302/71D is inactive for new design after 1 October 1986.
This specification is approved for used by all Departments and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification sheet and
MIL-DTL-55302.
FIGURE 1. Connectors, plug, .100 (2.54 mm) contact spacing, removable crimp socket.
AMSC N/A
FSC 5935
