MIL-DTL-55302/71D
Inches
mm
Inches
mm
Part or
Number
.050
1.27
.550
13.97
Identifying
of
Type of termination
.087
2.21
.600
15.24
Number
contacts
.100
2.54
.650
16.51
(PIN)
.150
3.81
.700
17.73
71-01
61
Solder
Figure 2
.200
5.08
.750
19.05
nonremovable
.250
6.35
.800
20.32
71-02
61
Crimp
Figure 1
.300
7.62
.850
21.59
removable
.350
8.89
.900
22.86
.400
10.16
.950
24.13
.450
11.43
1.000
25.40
.500
12.70
NOTE: Contacts 1, 20 and 61 are identified on the front face of the connector and all others are identified on the rear
face per the insert arrangement.
FIGURE 3. Insert arrangement for contact spacing connectors (female engaging face).
