INCH-POUND
MIL-DTL-55302/74D
12 November 2004
SUPERSEDING
MIL-C-55302/74C (USAF)
17 October 1986
DETAIL SPECIFICATION SHEET
CONNECTORS, PRINTED CIRCUIT SUBASSEMBLY AND ACCESSORIES,
PIN, RIGHT ANGLE, PLUG, ELECTRICAL, POLARIZED
FOR PRINTED WIRING BOARDS (.100 SPACING)
MIL-DTL-55302/74D is inactive for new design after 1 October 1986.
This specification is approved for use by all Departments and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification sheet and
MIL-DTL-55302.
Inches
mm
Inches
mm
.001
0.03
.093
2.36
.002
0.05
.097
2.46
.003
0.08
.100
2.54
.004
0.10
.125
3.18
.005
0.13
.140
3.56
.007
0.18
.145
3.68
.008
0.20
.158
4.01
.010
0.25
.162
4.11
.015
0.38
.274
6.96
.020
0.51
.310
7.87
.022
0.56
.386
9.80
.030
0.76
.436
11.07
.060
1.52
.564
14.33
.064
1.63
.076
1.91
FIGURE 1. Connectors, plug, .100 (2.54 mm) contact spacing, pin terminal.
AMSC N/A
FSC 5935
