MIL-DTL-55302/94F
Inches
mm
Inches
mm
.003
0.08
.185
4.70
.005
0.13
.235
5.97
.007
0.18
.250
6.35
.015
0.38
.270
6.86
.086
2.18
.276
7.01
.091
2.31
.320
8.13
.096
2.44
.330
8.38
.098
2.49
.340
8.64
.100
2.54
.400
10.16
.102
2.59
.410
10.41
.120
3.05
.450
11.43
.125
3.18
.462
11.73
.138
3.51
.625
15.88
.163
4.14
Dash
Number
Dimensions
number
of
A
B
C
D
E
F
G
M
contacts
±.006
±.006
±.006
±.006
±.006
±.006
(.015)
(.015)
(.015)
(.015)
(.015)
(.015)
01
24
1.100
1.236
1.240
1.400
1.900
2.200
1.260
1.270
(27.94)
(31.39)
(31.50)
(35.56)
(48.26)
(55.88)
(32.00)
(32.26)
02
28
2.300
2.436
2.440
2.600
3.100
3.400
2.460
2.470
(58.42)
(61.87)
(61.98)
(66.04)
(78.74)
(86.38)
(62.48)
(62.74)
03
72
3.500
3.636
3.640
3.800
4.300
4.600
3.600
3.670
(88.90)
(92.35)
(92.46)
(96.52)
(109.22)
(116.84)
(92.96)
(93.22)
04
96
4.700
4.836
4.840
5.000
5.500
5.800
4.860
4.870
(119.38)
(122.83)
(122.94)
(127.00)
(139.70)
(147.32)
(123.44)
(123.70)
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Unless otherwise specified, tolerances are ±.010 (0.25 mm).
4. Dimensions are .162 (4.11 mm) hex across the flats by .052 deep (1.32 mm) 4 places.
5. Keying sockets shown are in positions 4 and D.
6. Contacts (class A, in accordance with MIL-DTL-55302/97-01) are shipped loose in a plastic bag with each
connector unless otherwise specified. When contacts are furnished separately, the letters "WO" shall appear
immediately after the Part or Identifying Number (PIN) marking on the connector. Example:
M55302/93-02 WO.
7. For direct government procurements connectors shall be furnished with contacts in a plastic bag with each
connector.
FIGURE 1. Connector, receptacle (.100 inch spacing) Continued.
