MIL-DTL-55661C
4.4 Inspection covered by subsidiary documents. The following shall be inspected under the applicable
subsidiary documents as part of the inspection required by this specification and the inspection
requirement specified in the contract.
Where required
Item
Finish
3.6
Marking
3.7
4.5 Conformance Inspection.
4.5.1 Inspection of product for delivery. Inspection of product for delivery shall consist of Groups A and
B inspection.
4.5.1.1 Inspection lot. An inspection lot shall consist of all connectors of the same part number
produced under essentially the same conditions, and offered for inspection at one time.
4.5.1.2 Group A inspection. Group A inspection shall consist of the inspections specified in table II in
the order shown.
4.5.1.2.1 Sampling plan (Group A). Table II tests shall be performed on a production lot basis.
Samples shall be selected in accordance with Table IIa. If one or more defects are found, the lot shall be
screened for that particular defect and defects removed. A new sample of parts shall be selected in
accordance with Table IIa and all Group A tests again performed. If one or more defects are found in the
second sample, the lot shall be rejected and shall not be supplied to this specification.
4.5.1.2.2 Visual inspection (Group A inspection). Each connector shall be visually examined for
completeness, workmanship, and identification requirements. Attention shall be given to those
assemblies that require a gasket to determine the condition of the gasket. Gaskets missing, twisted,
buckled, kinked, or damaged in any way shall be cause for rejection.
TABLE II. Group A inspection.
Inspection
Requirement
Inspection
paragraph
paragraph
Visual and
3.11
4.9
mechanical
Continuity
3.9.1
4.6.1
Dielectric
3.9.2
4.6.2
withstanding
voltage
Insulation
3.9.3
4.6.3
resistance
NOTE: All electrical tests are considered major.
6
