MIL-DTL-641/20B
TABLE I. PIN.
Part
Terminal
Connection
Mounting
Switching action
number
1
4 breaks connected and monitor
Wirewrap
2
4 breaks connected and monitor
Solder lug
3
6 breaks
Wirewrap
Tip, ring
Double
and sleeve
lug
4
6 breaks
Solder lug
5
4 breaks and monitor
Wirewrap
6
4 breaks and monitor
Solder lug
TABLE II. Mating plugs.
Dash number
Mating plug
-1
-2
-3
M642/13-1, -2, -3, -4
-4
-5
-6
Marginal notations are not used in this revision to identify changes with respect to the previous issue due
to the extent of the changes.
Referenced documents. This document references MIL-DTL-641.
