INCH-POUND
MIL-DTL-83502/1G
10 February 2004
SUPERSEDING
MIL-PRF-83502/1F
3 July 1997
DETAIL SPECIFICATION SHEET
SOCKETS PLUG-IN ELECTRONIC COMPONENTS, ROUND STYLE
(T07, LOW PROFILE)
This specification is approved for use by all
Departments and agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification sheet and
MIL-DTL-83502.
45°
INDEX REF
SEE NOTE 9
SEE NOTE 5
SEE NOTE 4
250 MAX
A
.406 DIA
.012 MIN (SEE NOTE 8
MAX
.185 MAX
.230
.100
.025
DI A TYP
.017
FIGURE 1. Dimensions and configurations.
AMSC N/A
FSC 5935
