MIL-DTL-83502/1G
"A" dimension
Applicable
(pin circle)
dash
number
Inches
mm
-002, -021
.200
5.08
-005, -024
.200
5.08
-011, -030
.200
5.08
-014, -033
.230
5.84
-017, -036
.230
5.84
Inches
mm
0.25
.001
0.75
.003
0.43
.017
0.64
.025
0.98
.039
2.54
.100
4.65
.183
5.84
.230
6.35
.250
10.30
.406
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerance is .005 inch (0.13 mm).
4. Device to accept leads:
Lead diameter
Lead length
(mm)
(mm)
.017 +.003, -.001
Min
Max
(0.43 +0.08, -0.02)
.135
.160
(3.43) (4.06)
Contact shall be made at or before reaching a depth of .100 inch (2.54 mm).
5.
A visual polarization index to be provided in the first quadrant, design optional, one method shown.
6.
It is desirable that the socket face shall be relieved to facilitate removal of the integrated circuit.
7.
Socket is intended for soldering to a printed wiring board (PWB) having plated through holes with a
.039 inch (0.99 mm) diameter and a layout to suit the specific pin circle configuration.
8.
Bosses (stand offs) shall be so designed as to prevent spacing between socket body and mounting
board from being less than .012 inch (0.30 mm). This includes all dash numbers.
9.
Marking shall be on the package.
FIGURE 1. Dimensions and configurations - Continued.
