INCH-POUND
MIL-DTL-83502/3E
10 February 2004
SUPERSEDING
MIL-PRF-83502/3D
3 July 1997
DETAIL SPECIFICATION SHEET
SOCKETS PLUG-IN ELECTRONIC COMPONENTS,
ROUND STYLE (T08)
This specification is approved for use by all
Departments and agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification sheet and
MIL-DTL-83502.
.282 DIA
SEE NOTE 5
Inches
mm
Inches
mm
.510
.001
0.03
.140
3.56
MAX
.003
0.08
.282
7.16
.447
.010
0.25
.300
7.62
DIA
.441
.06
.015
0.38
.437
11.10
.050
1.27
.44
11.18
.06
1.5
.447
11.35
.093
2.36
.510
12.95
.670
17.02
.300 MIN
.670 MAX
.437 ±.001 RECOMMENDED
MOUNTING HOLE
62° ±.015 COUNTERSINK
.140 ±.010
.093 ±.003 DIA
.050 ±.003 DIA
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerance is ±.005 inch (0.13 mm).
4. Device to accept leads; .030 ±.003 inch (0.76 ±0.08 mm) diameter X .250 inch (6.35 mm). Contact
shall be made at or before reaching a depth of .190 inch (4.83 mm).
5. All other marking shall be on the package.
FIGURE 1. Dimensions and configurations.
AMSC N/A
FSC 5935
