MIL-DTL-83502/3E
TABLE I. Dash numbers and characteristics.
Dash
Number
Termination
Mating
Retention
number
of
type
force
force
M83502/3-
contacts
(maximum)
(minimum)
lbs (kg)
lbs (kg)
001
3
IV
8.0 (3.63)
8.5 (3.86)
REQUIREMENTS
Dimensions and configurations: See figure 1 and table I.
Reference material: See MIL-DTL-83502.
Body: Shall be TFE-fluorocarbon rod in accordance with ASTM D1710.
Contact: Beryllium copper in accordance with ASTM B139, ASTM B194, ASTM B103, or
UNS C729000 spinodal alloy in accordance with ASTM B740.
Contact finish: Gold, 30 microinches (0.76 µm) minimum over nickel in accordance with
MIL-DTL-83502.
Terminal: Brass in accordance with ASTM B16.
Sleeve finish: Gold over nickel plating in accordance with MIL-DTL-83502.
Part or Identifying Number (PIN): The PIN shall consist of the M prefix letter, basic specification
number, number of this specification sheet, and the dash number from table I.
Example:
83502/
3
-001
M
Dash numbers see table I
Detailed specification sheet
Basic specification number
M prefix
2
