INCH-POUND
MIL-DTL-83502/5D
10 February 2004
SUPERSEDING
MIL-PRF-83502/5C
3 July 1997
DETAIL SPECIFICATION SHEET
SOCKETS PLUG-IN ELECTRONIC COMPONENTS, ROUND STYLE
(R052)
This specification is approved for use by all
Departments and agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification sheet and
the MIL-DTL-83502.
.062 RAD X .050 DEEP
(OPTIONAL SEE NOTE 5)
SEE NOTE 6
.036
.096
.192
.119 MIN
.280 MAX
.366
MAX
.375
.370
FIGURE 1. Dimensions and configurations.
AMSC N/A
FSC 5935
