MIL-DTL-83502/5D
TABLE I. Termination style.
Dash number
Termination style
-003
Wire wrapping post, type I
-011
Printed circuit, type II
-013
Turrent, type III
-015
Solder pocket, type IV
REQUIREMENTS:
Dimensions and configurations: See figure 1 and table I
Termination styles: Type I, type II, type III, and type IV (see table I).
Mounting: See figure 1.
Temperature rating: +125°C.
Reference material: See MIL-DTL-83502.
Body: Shall be TFE-fluorocarbon rod in accordance with ASTM D1710.
Contact: Beryllium copper in accordance with ASTM B139, ASTM B194, ASTM B103, or C729000
spinodal alloy in accordance with ASTM B740.
Contact and sleeve finish: Gold over nickel in accordance with MIL-DTL-83502.
Terminal: Brass in accordance with ASTM B16.
Mating force: 4.0 pounds (1.81 kg) maximum.
Retention force: 3.0 pounds (1.36 kg) minimum.
5
