MIL-DTL-83503/6D
Marking:
Part or identifying number (PIN): The PIN shall consist of this specification sheet and the dash number from figure 1, table.
Example
M83503/6
-01
Basic document number
Dash number
Intended use: Connector may be directly soldered to a .093 inch printed wiring board or mated with the appropriate series
2
(low profile) dip socket in accordance with MIL-S-83734. These connectors when mated with MIL-S-83734 dip sockets are not
to be used in airborne applications.
TABLE II. Pin position.
Number of connections
Pin
position
8
14
16
18
22
24
28
40
A
4
7
8
9
11
12
14
20
B
5
8
9
10
12
13
15
21
C
8
14
16
18
22
24
28
40
4
