MIL-DTL-83513/2H
REQUIREMENTS:
Dimensions and configurations: See figure 1. This specification sheet describes the socket side of a
rectangular metal shell connector. This connector uses reverse gender contact, i.e., the live pin
recessed in the insulator with the static socket protruding from a shrouded interface.
Material and finish:
Shell: The requirements for shell materials shall be in accordance with MIL-DTL-83513.
Interfacial seal: Silicone rubber, or fluorosilicone rubber or blend thereof.
Contact identification: See figure 2 for contact layout identification.
Contact connection: The pin contact (being recessed in the insulator) is normally connected to the live
side of the circuit.
Current rating, maximum: 3 amperes per contact.
Mounting and mating hardware: Mounting hardware is to be ordered separately. Insert arrangements
A through G, shall be in accordance with MIL-DTL-83513/5, configurations A and B. Insert
arrangement H, shall be in accordance with MIL-DTL-83513/5, configuration C.
Mating plug: Shall be in accordance with MIL-DTL-83513/1 or MIL-DTL-83513/3.
Part or Identifying Number (PIN): PIN shall consist of the letter M, the basic number of the specification
sheet, a letter from the insert column and the shell finish.
M83513/02 -
A
C
Specification sheet
Insert arrangement
Shell finish
(Interface critical)
(see figure 2)
A = Pure electrodeposited aluminum
A=9
C = Cadmium
B = 15
K = Zinc nickel
C = 21
D = 25
N = electroless nickel
(space applications only)
E = 31
F = 37
P = Passivated Stainless Steel
T = Nickel Fluorocarbon Polymer
G = 51
H = 100
Changes from previous issue. The margins of this specification are marked with vertical lines to indicate
modifications generated by this amendment. This was done as a convenience only and the Government
assumes no liability whatsoever for any inaccuracies in these notations. Bidders and contractors are
cautioned to evaluate the requirements of this document based on the entire content irrespective of
marginal notations and relationship to the last previous issue.
