MIL-DTL-83517/1A
Inches
mm
Inches
mm
.001
.03
.050
1.27
PIN
"A" dim.
.020 ± .002
.002
.05
.065
1.65
M83517/1-31003
.004
.10
.100
2.54
.050 ± .001
M83517/1-31004
.005
.13
.102
2.59
.006
.15
.170
4.32
.010
.25
.340
8.64
.020
.51
.375
9.53
.510
12.95
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. All undimensioned pictorial configurations are for reference purposes only.
4. Number two screws are suggested for mounting.
FIGURE 2. Series SMA (four hole) flange mounted receptacle.
2
