MIL-DTL-83517/10A
Inches
mm
.001
.03
.010
.25
.015
.38
.0355
.90
.0370
.94
.050
1.27
.060
1.52
.100
2.54
.728
18.49
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. All undimensioned pictorial configurations are for reference purposes only.
4. See table I.
FIGURE 9. Transition pin (.060 inch contact).
Inches
mm
.001
.03
.002
.05
.010
.25
"A" dim.
Panel
Terminal Dia.
.051
1.30
.070 ±.002
.062
.010
.062
1.57
.132 ±.002
.125
.010
.070
1.78
.625 ±.002
.050
.125
3.18
.132
3.35
.162
4.11
NOTES:
.625
15.88
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. All undimensioned pictorial configurations are for reference purposes only.
4. See table I.
FIGURE 10. Rear dielectric.
9
