MIL-DTL-83538/1D
REQUIREMENTS:
Dimensions and configurations: See figures 1 and 2.
This connector mates with buffer plug MIL-DTL-83538/3.
Insert arrangement shall be in accordance with MIL-STD-1560 (25-20).
Adapter types: See MIL-DTL-83538/5. Use 0 designation for option when no adapter
type is needed.
Part or Identifying Number (PIN) example:
S
1
M83538/1
Specification sheet number
Contact (S or L)
Adapter type (see MIL-DTL-83538/5)
Marginal notations are not used in this revision to identify changes with respect to the previous issue
due to the extent of the changes.
Referenced documents. In addition to MIL-DTL-83538, this document references the following:
MIL-DTL-83538/3
MIL-DTL-83538/5
MIL-DTL-83538/6
MIL-STD-1560
MIL-STD-1760
