MIL-DTL-83538/4C
REQUIREMENTS:
Dimensions and configurations: See figures 1 and 2 and table I.
This connector mates with MIL-DTL-83538/3.
Insert arrangement shall be in accordance with MIL-STD-1560 (25-20).
The spigots shall be fitted in such a fashion as to meet the performance requirements in
MIL-DTL-83538.
Part or Identifying Number (PIN) example:
M83538/4
-
S
A
Specification sheet number
Contact (S or L)
Style
Marginal notations are not used in this revision to identify changes with respect to the previous issue
due to the extent of the changes.
Referenced documents. In addition to MIL-DTL-83538, this document references the following:
MIL-DTL-83538/3
MIL-STD-1560
MIL-STD-1760
