MIL-DTL-83723/27B
Shell size
Shell
P
R
S
T
designator
size
recovered
recovered
recovered
recovered
08
8S
.25
.46
.55
.040
10
10S
.26
.46
.55
.040
11
10SL
.29
.48
.59
.040
13
12S
.29
.48
.59
.040
12
12
.29
.48
.59
.040
15
14S
.33
.48
.60
.040
14
14
.33
.48
.60
.040
17
16S
.38
.48
.62
.040
16
16
.38
.48
.62
.040
18
18
.38
.48
.62
.040
20
20
.41
.55
.70
.063
22
22
.48
.60
.78
.065
24
24
.48
.60
.78
.065
28
28
.56
.60
.82
.065
32
32
.59
.63
.92
.080
36
36
.69
.63
.92
.080
40
40
.77
.63
.93
.080
NOTES:
1. Material:
a. Polyolefin.
b. Fluoroelastomer.
2. Boots will shrink to recovered dimensions upon application of heat in excess of 175°C.
FIGURE 3. Heat-shrinkable strain-relief boot, straight Continued.
