MIL-DTL-83723/35F
Cable entry
A
B
C
E
H
J
M
P thread
Shell
1/
max
dia
dia
max
max
max
class 2B
size
dia
Max
Min
8
.805
.455
.300
1.187
.350 .285 1.220 .438-28 UNEF
.235
.102
.440
.279 (30.15)
.272
10
.890
.520
.360
1.187
.350 .285 1.250 .500-28 UNEF .235 .102
.500
.339 (30.15)
.272
11
.975
.580
.430
1.312
.350 .285 1.280 .562-24 UNEF .297 .140
.560
.408 (33.32)
.272
13
1.005
.645
.480
1.312
.350 .285 1.280 .625-24 UNEF .297 .140
.625
.459 (33.32)
.272
12
1.005
.645
.480
1.468
.505 .441 1.280 .625-24 UNEF .297 .140
.625
.459 (37.29)
.428
15
1.130
.770
.584
1.437
.355 .285 1.405 .750-20 UNEF .422 .195
.750
.562 (36.50)
.272
14
1.130
.770
.584
1.594
.510 .441 1.405 .750-20 UNEF .422 .195
.750
.562 (40.49)
.428
17
1.255
.895
.710
1.531
.350 .285 1.529 .875-20 UNEF .547 .255
.875
.688 (38.89)
.272
16
1.255
.895
.710
1.687
.510 .441 1.529 .875-20 UNEF .547 .255
.875
.688 (42.85)
.428
18
1.350 1.020
.827
1.765
.490 .441 1.593 1.000-20 UNEF .610 .285
1.000
.805 (44.83)
.428
20
1.475 1.145
.962
2.000
.495 .441 1.655 1.125-18 UNEF .735 .350
1.125
.942 (50.80)
.428
22
1.600 1.270
1.095
2.000
.495 .441 1.718 1.250-18 UNEF .735 .350
1.250
1.073 (50.80)
.428
24
1.725 1.395
1.202
2.265
.488 .423 1.894 1.375-18 UNEF .922 .468
1.375
1.180 (57.53)
.410
28
1.975 1.645
1.423
2.265
.488 .423 1.973 1.625-18 UNEF .922 .468
1.625
1.401 (57.53)
.410
32
2.225 1.895
1.674
2.578
.488 .423 2.187
1.875-16 UN 1.235 .664
1.875
1.652 (65.48)
.410
36
2.475 2.145
1.887
2.815
.488 .423 2.405
2.125-16 UN 1.360 .694
2.125
1.865 (71.50)
.410
40
2.750 2.390
2.125
5.800
.500 .423 5.100
2.375-16 UN 1.630 .911
2.375
2.117 (147.23)
.410
1/ "Cable entry" dimension is defined as the envelope area for the wire bundle. This dimension is not
intended to define the clamp hardware limits.
FIGURE 3. Type A - 90 clamp - Continued.
REQUIREMENTS:
Material: Aluminum alloy in accordance with ASTM-B-85 Aluminum Alloy Die Castings, Stainless Steel
in accordance with ASTM A967, Aluminum black anodize in accordance with MIL-A-8625.
6
