INCH-POUND
MIL-DTL-83723/37B
23 May 2003
SUPERSEDING
MIL-C-83723/37A(USAF)
1 October 1975
DETAIL SPECIFICATION SHEET
CONNECTOR, ELECTRICAL, (CIRCULAR, ENVIRONMENT RESISTING),
PLUG, (BAYONET COUPLING, PREWIRED, SOCKET CONTACT),
(SERIES I, CLASSES A, G, AND R), (SHELL SIZE 8 FOR INSERTS 8-2, 8-3, AND 8-4 ONLY)
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein
shall consist of this specification and MIL-DTL-83723.
Inactive for new design as of
25 May 1993.
FIGURE 1. Completed assembly.
AMSC N/A
1 of 6
FSC 5935
DISTRIBUTION STATEMENT A. Approved for public release, distribution is unlimited.
