MIL-DTL-83723/37B
REQUIREMENTS
Dimensions and configuration: See figure 1.
For insert arrangements: See MIL-STD-1669.
Rear hardware shall be in accordance with MIL-C-83723/16, /23, and MIL-C-85049/31, /51, /52, /60.
Contacts and leads shall be furnished in assembled configuration.
Connector assembly must include a backshell to meet moisture sealing requirements.
Shell material: Class A and R Aluminum alloy in accordance with SAE-AMS-QQ-A-367.
Class G Corrosion resistant steel in accordance with SAE-AMS-QQ-S-763.
Circumferential color bands specified in MIL-C-26482 do not apply.
Connector identification marking specified in MIL-C-26482 does not apply. Marking shall be as
specified in the Part or Identifying Number (PIN) below.
PIN example:
37
R
08
02
N
M83723/
Military designator
Specification sheet number
Class
Shell size
Insert arrangement
Polarizing position
CONCLUDING MATERIAL
Custodians:
Preparing activity:
Army - CR
DLA - CC
Navy - AS
Air Force - 11
(Project 5935-4415-003)
DLA - CC
Review activities:
Air Force - 70, 80, 84, 99
6
