MIL-DTL-83723-83 Connectors, Electrical, \(Circular, Environment Resisting\), Receptacle, \(Flange Mount, Threaded Coupling, Crimp Pin Contact\), \(Series Iii, Classes A, G, K, M, N, R, S, T, W And Z\)

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8


MIL-DTL-83723/83E
Inches
mm
.116
2.95
.125
3.18
Shell size
A thread
B max
D max
F max
C
coupling thread
8
.562-24 UNEF-2A
.394
.290
.562
.418
.413
10
.688-24 UNEF-2A
.515
.388
.696
.535
.530
12
.875-20 UNEF-2A
.685
.558
.875
.705
.700
14
.938-20 UNEF-2A
.754
.627
.936
.774
.769
16
1.062-18 UNEF-2A
.881
.772
1.062
.901
.896
18
1.188-18 UNEF-2A
.987
.860
1.187
1.007
1.002
20
1.312-18 UNEF-2A
1.112
.985
1.312
1.132
1.127
22
1.438-18 UNEF-2A
1.237
1.110
1.437
1.257
1.252
24
1.562-18 UNEF-2A
1.362
1.235
1.562
1.382
1.377
FIGURE 3. Dimensions and configurations.
6
