MIL-DTL-83723/83E
R
Shell size
G
H
S
T
number of
+.005 / -.000
teeth
8
.594
.812
12
.490
.076
.071
10
.719
.937
15
.636
12
.812
1.031
21
.806
14
.906
1.125
24
.875
.089
16
.969
1.250
30
1.002
.084
18
1.062
1.343
33
1.108
20
1.156
1.437
36
1.233
22
1.250
1.562
39
1.358
24
1.375
1.703
42
1.483
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Unless otherwise specified, tolerances are ± .005 (0.13 mm) for three place decimals and
± .01 (0.25 mm) for two place decimals and ± 1° for all angles.
4. Coupling indicator line shall be color coded red.
5. Rear accessory interchangeability dimensions shall be in accordance with MIL-DTL-83723.
6. Shell size 8 will not mate with MIL-DTL-26500 connectors.
7. Phantomed configuration optional.
8. See table I for contact cavities requiring this dimension.
9. The centerline of indicated projection must be located on vertical centerline ± 2°.
FIGURE 3. Dimensions and configurations - Continued.
REQUIREMENTS:
Dimensions and configurations: See figures 1 and 3 for classes A, G, K, M, R, T, W and Z.
See figures 2 and 3 for classes N and S.
This connector mates with MIL-DTL-83723/86, MIL-DTL-83723/91 and MIL-DTL-83723/95 and
MIL-C-83723/97.
Insert arrangements and polarizing positions: See MIL-STD-1554 and table I.
TABLE I. Insert arrangements requiring reduced diameter for raised
seal barriers on outer row of contact cavities as indicated.
Shell size
Insert arrangements
Contact cavities
8
03, 98
1, 2, 3
10
06
1, 2, 3, 4, 5, 6
7
