INCH-POUND
MIL-DTL-83723/98C
21 May 2010
SUPERSEDING
MIL-C-83723/98B
24 April 1992
DETAIL SPECIFICATION SHEET
CONNECTORS, ELECTRICAL, (CIRCULAR, ENVIRONMENT RESISTING),
PLUG, (THREADED COUPLING, SELF-LOCKING, R.F.I. GROUNDING,
CRIMP PIN CONTACT), (SERIES III, CLASSES N AND S FIREWALL)
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein
shall consist of this specification sheet and MIL-DTL-83723.
1.280 MAX.
.510
PLANE "Y"
.500
SEE NOTE 6
.400
.260 MIN. THD.
.235 THD START
ENG'T LENGTH
.215 (SEE NOTE 4)
.068
.775 MAX.
.048
COUPLING
(REF)
RING
A COUPLING THD
(SEE NOTE 4)
.061
A
.035
.007 R
MAX.
90°
K
B DIA. MAX
TYP
DIA. J H DIA. MIN. INSERT
S
MIN. DIA. SHELL
30°
SEE
NOTE 5
.160
C
.010
KNURL
MARKING-LOCATION
OPTIONAL
FIGURE 1. Dimensions and configurations.
FSC 5935
AMSC N/A
