MIL-DTL-83723/98C
Requirements:
Dimensions and configuration: See figure 1.
This connector mates with MIL-DTL83723/82 and /84.
Insert arrangements and polarizing positions: See MIL-STD-1554 and table I.
TABLE I. Insert arrangements requiring reduced diameters for raised seal barrier on outer row of
the cavities as indicated.
Shell size
Insert
Contact cavities
arrangements
8
03
1,2,3
10
06
1,2,3,4,5,6
Connector accessories: See SAE-AS85049.
RFI spring strip shall have a minimum of six fingers per inch and shall point to the rear of the
connector.
Part or Identifying Number (PIN) example.
M
83723/98
S
22
55
N
Military designation
Specification sheet
Class (see MIL-DTL-83723)
Shell size
Insert arrangement
Polarizing position
5
