MIL-DTL-83734/17A
REQUIREMENTS:
Design and construction:
Dimensions and configurations: See figure 1 and table I.
Material and contact finish: In accordance with MIL-DTL-83734.
Termination's (see table I and MIL-DTL-83734).
a.
Type I; Solderless wrap.
b.
Type II; Printed circuit terminal.
Contact identification: See figure 1 and note 6.
Part or Identifying Number (PIN): The PIN shall consist of this specification sheet and the dash number from table I.
Example:
M83734/17
-001
Basic document number
Dash number (dash number from table I)
TABLE I. Dash numbers and characteristics.
Dash number
Termination
Length
Contact
Termination
Number
M83734/17
type
L
engagement
finish
of wrap
Min
area finish
levels
-001
I
.185
Gold
Gold
1
-002
I
.185
Gold
Tin/lead
1
-003
I
.185
Tin/lead
Tin/lead
1
-004
I
.320
Gold
Gold
2
-005
I
.320
Gold
Tin/lead
2
-006
I
.320
Tin/lead
Tin/lead
2
-007
I
.485
Gold
Gold
3
-008
I
.485
Gold
Tin/lead
3
-009
I
.485
Tin/lead
Tin/lead
3
-013
II
.120
Gold
Gold
N/A
-014
II
.120
Gold
Tin/lead
N/A
-015
II
.120
Tin/lead
Tin/lead
N/A
1/ For replacement purposes, the Government will stock, store, and issue -001, -004, -007, and -013
parts only. (See MIL-DTL-83734.)
NOTE: Revision letters are not used to denote changes due to the extensiveness of the changes.
CONCLUDING MATERIAL
Custodians:
Preparing activity:
Army - CR
DLA - CC
Navy - EC
Air Force - 11
(Project 5935-4329-14)
DLA - CC
Review activities:
Navy - AS, MC, OS, SH, TD
Air Force - 19, 99
3
