MIL-DTL-9177/5C(USAF)
Inches
mm
Inches
mm
Inches
mm
Inches
mm
31.72
1.249
10.95
.431
5.16
.203
0.25
.010
31.75
1.250
11.15
.439
5.56
.219
0.38
.015
38.89
1.531
14.27
.562
6.32
.249
0.64
.025
43.2
1.70
14.63
.576
7.16
.282
1.14
.045
43.66
1.719
16.00
.630
7.32
.288
1.98
.078
45.7
1.80
20.37
.802
7.87
.310
2.74
.108
48.03
1.891
21.44
.844
7.90
.311
3.12
.123
51.18
2.015
24.76
.975
7.92
.312
3.18
.125
59.51
2.343
25.37
.999
8.79
.346
3.38
.133
61.09
2.405
28.58
1.125
8.89
.350
3.45
.136
29.51
1.162
10.03
.395
4.34
.171
30.02
1.182
10.19
.401
5.00
.197
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerance is ± .005 (0.13 mm).
4. All dimensions are after plating.
5. If the jack passes the electrical continuity test using the test plug, this will be accepted as evidence
that the jack meets the contact location requirements.
6. All undimensioned pictorial representations are for reference purposes only.
7. Switch shall be in accordance with MIL-PRF-8805/3, part number MS25089-4B.
FIGURE 2. Dimensions and configurations (M9177/5-2) Continued.
10
