MIL-DTL-9177/5C(USAF)
mm
Inches
mm
Inches
mm
Inches
mm
Inche
s
.010
0.25
.203
5.16
.431
10.95
1.249
31.72
.015
0.38
.219
5.56
.439
11.15
1.250
31.75
.025
0.64
.249
6.32
.562
14.27
1.531
38.89
.045
1.14
.282
7.16
.576
14.63
1.70
43.2
.078
1.98
.288
7.32
.630
16.00
1.719
43.66
.108
2.74
.310
7.87
.802
20.37
1.80
45.7
.123
3.12
.311
7.90
.844
21.44
1.891
48.03
.125
3.18
.312
7.92
.975
24.76
2.015
51.18
.133
3.38
.346
8.79
.999
25.37
2.343
59.51
.136
3.45
.350
8.89
1.125
28.58
2.405
61.09
.171
4.34
.395
10.03
1.162
29.51
.197
5.00
.401
10.19
1.182
30.02
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerance is ± .005 (0.13 mm).
4. All dimensions are after plating.
5. If the jack passes the electrical continuity test using the test plug, this will be accepted as evidence
that the jack meets the contact location requirements.
6. All undimensioned pictorial representations are for reference purposes only.
7. Switch shall be in accordance with MIL-PRF-8805/3, part number MS25089-4B.
FIGURE 1. Dimensions and configurations (M9177/5-1) Continued.
5
