MIL-PRF-31031/11B
TABLE II. Cable retention force.
Torque
Cable
Pounds (minimum)
(minimum)
MIL-C-17/130
60
55
group XVI
MIL-C-17/133
30
16
group XVII
1/ Torque to be applied 4 inches maximum from the end of the
connector reverse bend not applicable.
TABLE Ill. Group qualification. 1/ 2/ 3/ 4/
Group
Submission and qualification of
Qualifies the
any of the following connectors
following connectors
1
M31031/11E**02
M31031/11E**01
M31031/11E**02
* Options as defined in the PIN construction.
1/ Individual connectors other than those listed are self-qualifying.
2/ Qualification of connectors qualifies connectors of the same body materials only.
3/ Qualification of connectors qualifies connectors of the same environmental
construction only.
4/ Changes in plating (body or center contact) shall require the corrosion and contact
resistance tests be performed.
ENGINEERING DATA
Nominal impedance: 50 ohms ± 1 ohm.
Frequency range: 0 to 18 GHz (frequency limit is dependent on cable used).
Voltage rating:
MIL-C-17/130 and group XVI: 500 V rms at sea level: 125 V rms at 70,000 feet.
MIL-C-17/133 and group XVII: 335 V rms at sea level: 85 V rms at 70,000 feet.
Temperature rating: -65°C to +125°C.
