MIL-PRF-31031/12A
TABLE I. Part or Identifying Number (PIN) cross-reference and dimensions. 1/
PIN 2/
Applicable cable
Inches
M31031/12
and group 3/
Dimensions
(millimeters)
M17/
maximum
Category E - field serviceable (no special tools required) 4/
E**01
130-RG402
A
.710
Group XVI
(18.03 mm)
E**02
133-RG405
A
.710
Group XVII
(18.03 mm)
1/ The cables are to be used when performing tests. However, all the
cables in the specification sheet must accommodate the connectors.
2/ These connectors have captivated center contacts.
3/ The latest version of the cable is applicable.
4/ Kit number - Omni Spectra T-200. Amphenol 901-2500 or equivalent.
TABLE II. Cable retention force.
Cable
Pounds minimum
Torque minimum
MIL-C-17/130
60
55
Group XVI
MIL-C-17/133
30
16
Group XVII
1/ Torque to be applied 4 inches maximum from the end of the connector
reverse bend not applicable.
TABLE III. Group qualification. 1/ 2/ 3/ 4/
Group
Submission and qualification of
Qualified the
any of the following connectors
following connectors
I
M31031/12E**02
M31031/12E**01
M31031/12E**02
*
Options as defined in the PIN construction.
1/ Individual connectors other than those listed are self-qualifying.
2/ Qualification of connectors qualifies connectors of the same body materials only.
3/ Qualification of connectors qualifies connectors of the same environmental construction
only.
4/ Changes in plating (body or center contact) shall require the corrosion and contact
resistance tests be performed.
2
