MIL-PRF-39012/28H
TABLE I. Dash numbers, cross-reference, and dimensions Continued.
PIN 1/
Applicable cable 2/
Dimensions
Inches (millimeters)
M39012/28-
M17/
maximum #
Category C field replaceable (MIL-DTL-22520 crimp tool)
See note next to applicable cable for crimp die 3/ 7/
X010
Cable group VIA 6/ 8/
111-RG303 4/ 5/
X011
Cable group VIB 6/ 8/
60-RG142 4/
128-RG400 5/
X012
Cable group VIIA 6/ 9/
A
1.625 (41.28)
110-RG302 4/ 5/
Cable group IV 6/ 10/
X013
54-RG122 5/
Cable group VIIB 6/ 9/
X014
90-RG71 5/
Cable group IIA 6/ 11/
X022
113-RG316 4/ 5/
Cable group V 6/ 10/
X023
95-RG180 5/
Category D Field replaceable Defined piece part 3/ 7/ 12/ 13/
X501
Cable group IV 6/
A
1.234 (31.35)
54-RG122 5/
