MIL-PRF-39012/28H
Inches
mm
Inches
mm
Inches
mm
Inches
mm
.001
0.03
.033
0.84
.145
3.68
.220
5.59
,002
0.05
.035
0.89
.175
4.45
.230
5.84
.003
0.08
.040
1.02
.183
4.65
.235
5.97
.005
0.13
.043
1.09
.206
5.23
.250
6.35
.015
0.38
.067
1.70
.210
5.33
.478
12.14
.017
0.43
.083
2.11
.212
5.38
.500
12.70
Color
Color band
Crimp
band
A
Tensile min.
Contact No.
Crimp die or
Basic crimp tool
+0.001
Dash No.
(N)
1/
positioner
2/
-0.002
10 lbs.
X501
28-12
0.033
Orn
(44.48)
M22520/1-01
M22520/1-12
6 lbs.
X502
28-11
0.017
Blue
Blue
(26.69)
X503
20 lbs.
28-10
0.043
M22520/1-01
M22520/1-12
Red
X504
(88.96)
1/ Contact numbers and ferrule numbers are for identification only.
2/ Class 2 tool may be used by OEM (see MIL-DTL-22520).
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Contact material shall be copper beryllium. Connectors supplied with phosphor bronze
contacts are no longer acceptable for Government use.
4. Crimp tensile test shall be in accordance with SAE-AS39029.
5. Copyright notice: All information disclosed in these specification sheets which is or may be copyright
is reproduced herein with the express permission of the copyright owner.
6. .003 inch maximum break.
7. Color bands shall be positioned so that no coloring material enters the inspection hole.
FIGURE 3. Contact and ferrule dimensions for category D only Continued.
7
