MIL-PRF-39012/3H
Crimp die or
A
B
Basic crimp
Dash
Ferrule
C ± .015
positioner
± .003
± .003
number 1/
tool 2/
number
M22520/5-
X501
3-50
.492
.438
.600
25
Closure A
X502
3-51
.492
.418
.600
or 61
M22520/5-
X503
3-52
.250
.220
.500
5, 11, 57
01
Closure A
or 19
X504
3-53
.245
.206
.500
Closure B
1/ Ferrule numbers are for identification only.
2/ Class 2 tools may be used by OEM (see MIL-DTL-22520).
FIGURE 3. Contact and ferrule dimensions for category D only Continued.
8
