MIL-PRF-39012/30H
40 pounds (177.93 N), minimum for cables .250 inch (6.35 mm) OD and larger.
Coupling mechanism retention force: 100 pounds 444.82 N), minimum.
RF Leakage: -60 dB minimum, tested at a frequency between 2 and 3 GHz.
Insertion loss:
.21 dB maximum tested at 9 GHz.
.07
F (GHz) dB max tested at 3 GHZ to 6 GHz.
PIN: M39012/30 (dash number from table I or "B" number from table III).
Group qualification: See table II.
TABLE II. Group qualification. 1/
Submission and qualification of any of
Qualifies the following
Group
the following connectors 2/
connectors 2/
M39012/30
M39012/30
I
-X101
-X101
-X103
-X102
-X018
-X103
-X018
-X225
II
-X002
-X102
-X017
-X017
III
B0005
B0005
B0006
B0006
B0008
B0007
B0015
B0008
B0016
B0009
B0020
B0015
B0016
B0019
B0020
IV
B0007
B0007
B0009
B0009
B0019
B0019
V
-X010
-X010
-X011
-X011
-X013
-X012
-X022
-X013
-X023
-X014
-X021
-X022
-X023
VI
-X012
-X012
-X017
-X014
-X021
-X021
-X501
VII
-X501
-X502
-X503
-X503
-X504
-X504
VIII
-X502
-X502
10
