MIL-PRF-39012/30H
TABLE II. Group qualification Continued.
1/ If a connector manufacturer produces a connector which meets all the requirements for two or more
connector PINs (within the same series), the manufacturer may receive qualification approval for two or
more connector PINs qualifying the one connector. It is not necessary that such connectors be in the
same group. Each connector, however, must be marked with its own appropriate PIN. For group
qualification, the connectors must be of similar design and be of the same materials and plating.
2/ For qualification retention, where more then one part is listed in a group in this column, data may be
supplied on any of those parts in order to retain qualification for those parts in the corresponding right
hand column. The part does not necessarily have to be the part initially qualified.
TABLE III. Category B nonfield replaceable (special tools may be required).
.
Not for Air Force, Army, or Navy use. For OEM use only.
Applicable
Inches
Dash number
cable M17/
Dimensions
(millimeters)
1/ 2/ 3/
4/
maximum 5/
M39012/30B0005
28-RG058*
M39012/30B0006
60-RG142*@
128-RG400
M39012/30B0007
29-RG59*^
30-RG062 ^
A
2.00 (50.80)
97-RG210 ^
M39012/30B0008
54-RG122*
M39012/30B0009
90-RG71*^
M39012/30B0015
111-RG303*@
M39012/30B0016
84-RG223 *
M39012/30B0019
110-RG302 *@ ^
84-RG223 @
M39012/30B0020
113-RG316* @
1/
For cross-reference of dash number to superseded PIN or type designation, see table IV.
2/
For maintenance replacements for category B, see table V.
3/
Inactive for new design.
4/
The latest version of each cable shall be applicable.
5/
Dimensions are in inches. Metric equivalents are given for information only.
* Cable to be used when performing tests requiring cable except as in notes @ and ^.
@ Cable to be used for the +200°C temperature cycling tests. This cable can be used for tests with
the approval of the Qualifying Activity.
^ These are not 50 ohm cables; therefore, when attached to the specified connectors, VSWR, RF
leakage, and Insertion loss are not applicable.
