MIL-PRF-39012/35H
Cable retention force:
Non-crimp assemblies: 75 pounds (333.62 N) minimum.
Crimp assemblies:
50 lbs. minimum for cables .155 -.189 inch OD.
60 lbs. minimum for cables .190 - .229 inch OD.
75 lbs. minimum for cables .230 - .249 inch OD.
90 lbs. minimum for cables .250 inch OD and larger.
Coupling mechanism retention force: 100 pounds, minimum.
RF leakage: -90 dB minimum, tested at a frequency between 2 and 3 GHz..
RF insertion loss:
.15 dB maximum at 9 GHz.
.05 √ F (GHz) dB maximum tested at 3 and 6 GHz.
PIN: M39012/35 - (dash number from table I or `B number from table III).
Group qualification: See table II.
TABLE II. Group qualification and retention testing. 1/
Group
Submission and qualification of
Qualifies the following
any of the following connectors 2/
connectors
M39012/35
M39012/35
I
-0017
-0015
-0016
-0017
-0018
-0019
-0020
-0021
-0022
See notes at end of table.
10
