MIL-PRF-39012/35H
TABLE III. Category B non-field replaceable (special tools may be required). 1/
NOT FOR ARMY, NAVY, OR AIR FORCE USE. FOR OEM USE ONLY
PIN 2/ 3/
Applicable cable 4/
Dimensions
Inches (millimeters)
M39012/35B
M17/
Maximum
0023
73-RG212 5/
112-RG304
0024
65-RG165 6/
A
2.250 (57.15)
74-RG213 5/
B
.828 (21.03)
0025
75-RG214 5/
86-00001 6/
0026
6-RG11 5/ 7/
62-RG144 6/ 7/
0027
92-RG115 6/
See notes at end of table.
1/ For maintenance replacements for category B, see table V.
2/ For cross-reference of dash number to superseded PIN or type designation, see table IV.
3/ These connectors have captivated center contacts.
4/ The latest version of each cable shall be applicable.
5/ Cable to be used when performing test requiring cable except as in 6/ and 7/.
6/ Cable to be used for the +200ēC temperature cycling tests.
7/ These are not 50 ohm cables; therefore, when attached to the specified connectors, VSWR, RF
leakage, and insertion loss are not applicable.
12
