MIL-PRF-39012/57H
Shock: In accordance with MIL-STD-202, method 213, test condition I.
Thermal shock: In accordance with MIL-STD-202, method 107, test condition B, except test high
temperature shall be +85°C. High temperature shall be +200°C for connectors using +200°C cables
(see tables I and V).
Moisture resistance: In accordance with MIL-STD-202, method 106. No measurements at high
humidity. Insulation resistance shall be at least 200 megohms within 5 minutes after removal from
humidity.
Corona level:
Altitude: 70,000 feet (4.437 kPa).
Cable group
Volts, min.
I
125
II, IIa, III, IV
190
VI, VIa, VIb
250
RF high potential withstanding voltage:
Voltage and frequency: Tested at a frequency from 5 to 7.5 MHz.
Leakage current: Not applicable.
Cable group
Volts, min.
I
335
II, IIa, III, IV
500
VI, VIa, VIb
670
Cable retention force: The cable retention force shall be in accordance with table III.
TABLE III. Cable retention force.
Cable dielectric
Pounds, min. (N)
Outer diameter 1/
Single braid
Double braid
Inches, max. (mm)
.036 (0.91)
10 (44.48)
N/A
.067 (1.70)
20 (88.96)
N/A
.110 (2.79)
30 (133.45)
N/A
.122 (3.10)
40 (177.93)
45 (200.17)
1/ Dimensions are in inches. Metric equivalents are given for information only.
Coupling mechanism retention force: Not applicable.
RF leakage: -60 dB minimum, tested at frequency between 2 and 3 GHz.
10
