MIL-PRF-39012/57H
TABLE I. Dash numbers, cross-reference, and dimensions Continued.
Dash No. 1/ @
# Applicable cable
Dimensions
Inches 2/
group from MIL-PRF-
(millimeters)
39012, appendix B
Maximum
CATEGORY C FIELD REPLACEABLE (MIL-C-22520/5 CRIMP TOOL)
SEE FOOTNOTE NEXT TO APPLICABLE CABLE GROUP FOR CRIMP DIE 7/
3025
Cable group I 8/
4025
M17/93-RG178 4/ 5/
3026
Cable group IIa 9/
4026
M17/113-RG316 4/ 5/
3027
Cable group IV 10/
4027
M17/54-RG122 4/ 5/
3028
Cable group VIb 11/
A
1.265 (32.13)
4028
M17/84-RG223 4/
M17/128-RG400 5/
M17/60-RG142 6/
3029
Cable group VIa 11/
4029
M17/28-RG058 4/
M17/111-RG303 5/
CATEGORY D FIELD REPLACEABLE DEFINED PIECE PARTS 4/ 12/ 13/
3502
Cable group VIb
4502
M17/60-RG142 4/ 6/
A
1.265 (32.13)
M17/128-RG400 5/
1/
These connectors have captivated center contacts.
2/
Dimensions are in inches. Metric equivalents are given for information only.
3/
All corrosion resistant steel bodied connectors which are designed to be assembled to the outer
conductor using solder shall be gold plated in accordance with ASTM B488, type II, code C, class 1.27.
4/
Cable to be used when performing tests except as in note 6/.
5/
Preferred cable.
6/
Cable to be used for +200°C temperature cycling test.
7/
These connectors are assembled, using the applicable crimp tool, to the specified cables stripped as
shown on figures 3 and 4.
8/
Preferred die M22520/5-33 closure B, alternate die M22520/5-03 closure B.
9/
Preferred die M22520/5-35 closure B, alternate die M22520/5-03 closure A.
10/
Preferred die M22520/5-41 closure B, alternate die M22520/5-05 closure B or -09 closure A.
11/
Preferred die M22520/5-19 closure B, alternate die M22520/5/-05 closure A or -11, 57 closure A.
12/
Complete connector assembly shall consist of a body, center contact, ferrule and assembly instructions.
13/
Not for use in Army equipment.
#
The latest version of each cable shall be applicable.
*
These parts are inactive for new design, new designs should procure to dash numbers X009 and X109.
These dash numbers use the same cable group (VI).
@
Connectors mate with connectors of the same material; i.e., "3XXX" series dash numbers mate only with other
"3XXX" series connectors and "4XXX" series connectors with other "4XXX" series connectors.
4
