MIL-PRF-39012/58H
Vibration, high frequency: In accordance with MIL-STD-202, method 204, test condition D.
Shock: In accordance with MIL-STD-202, method 213, test condition I.
Thermal shock: In accordance with MIL-STD-202, method 107, test condition B, except test high
temperature shall be +85°C. High temperature shall be +200°C for connectors using +200°C cables
(see tables I and V).
Moisture resistance: In accordance with MIL-STD-202, method 106. No measurements at high
humidity. Insulation resistance shall be at least 200 megohms within 5 minutes after removal from
humidity.
Corona level:
Altitude: 70,000 feet (4.437 kPa).
Cable group
Volts, min.
I
125
II, IIa, III, IV
190
VI, VIa, VIb
250
RF high potential withstanding voltage:
Voltage and frequency: Tested at a frequency from 5 to 7.5 MHz.
Leakage current: Not applicable.
Cable group
Volts, min.
I
335
II, IIa, III, IV
500
VI, VIa, VIb
670
Cable retention force: The cable retention force shall be as specified in table III.
TABLE III. Cable retention force.
Cable dielectric
Pounds, min. (N)
Outer diameter
Single braid
Double braid
Inches, max. (mm)
.036 (0.91)
10 (44.48)
N/A
.067 (1.70)
20 (88.96)
N/A
.110 (2.79)
30 (113.45)
N/A
.122 (3.10)
40 (177.93)
45 (200.17)
Coupling mechanism retention force: Not applicable.
10
