MIL-PRF-39012/67C
TABLE I. Dash numbers, cross-reference, and dimensions.
Dash No.
# Applicable cable group
Typical mating
Dimensions
Inches
from MIL-PRF-39012,
connector
(millimeters)
1/
M39012/67-
appendix B
maximum
M17/
2/
CATEGORY A FIELD SERVICEABLE (NO SPECIAL TOOLS REQUIRED)
Cable group I
0003 3/ 4/
M39012/68-0003
93-RG178 * @
M39012/70-0003
169-00001 %
Cable group II
0004 3/ 4/
M39012/68-0004
A
.88 (22.35)
113-RG316 * @
M39012/70-0004
172-00001 %
94-RG179 ^
Cable group I
0103 3/
M39012/68-0103
93-RG178 * @
M39012/70-0103
169-00001 %
Cable group II
0104 3/
M39012/68-0104
113-RG316 * @
M39012/70-0104
172-00001 %
94-RG179 ^
Cable group I
4101 3/
M39012/68-4101
93-RG178 * @
M39012/70-4101
169-00001 %
Cable group II
4102 3/
M39012/67-4102
M39012/69-4102
113-RG316 * @
172-00001 %
94-RG179 ^
CATEGORY C FIELD REPLACEABLE (MIL-C-22520/5 BASIC CRIMP TOOL) 5/
Cable group I ~
0011 3/ 4/
M39012/68-0011
93-RG178 * @
M39012/70-0011
169-00001 %
A
1.10 (27.94)
Cable group IIa &
0012 3/ 4/
M39012/68-0012
113-RG316 * @
M39012/70-0012
172-00001 %
94-RG179 ^
See notes at end of table.
