MIL-PRF-39012/69C
Inches mm
Inches
mm
.002 0.05
.015
0.38
.005 0.13
.027
0.69
.006 0.15
.028
0.71
.007 0.18
.036
0.91
.009 0.23
.037
0.94
.010 0.25
.131
3.33
.011 0.28
.141
3.58
.012 0.30
.145
3.68
.014 0.36
.146
3.71
A
B
C
D
E
.037
.015
.010
GAUGE #1
.036
.014
.009
.005 Max.
.006
Rad.
.002
.028
.012
.007
Rad.
GAUGE #2
.027
.011
.006
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Gauge #1 to be used for longitudinal force initial engagement, and maximum engagement
requirement after 500 cycles.
4. Gauge #2 to be used for minimum disengagement requirement after 500 cycles of nating and
unmating.
5. Material steel with a 16 microinch finish.
FIGURE 3. Test gage for force to engage and disengage test.
5
