MIL-PRF-39012/73C
ENGINEERING DATA:
Nominal impedance: 50 ohms.
Frequency range: 0 to 10 GHz.
Voltage rating: The voltage rating shall be as specified in table II.
Temperature rating: -65°C to +165°C.
TABLE II. Voltage rating.
Cables
Voltage max. (sea level)
Voltage max. at 70,000 ft.
V rms
(4.437 kPa)
V rms
Cable group I
250
60
Cable group II, IIa,
335
85
REQUIREMENTS:
Dimensions and configuration: See figure 1 and MIL-STD-348.
Force to engage and disengage:
Longitudinal force: Not applicable.
Torque: 16 inch-ounces, maximum.
Coupling proof torque: 100 inch-ounces, minimum.
Inspection conditions:
Torque: 35 to 50 inch-ounces.
Mating characteristics: See MIL-STD-348.
Center contact (socket):
Oversize test pin: .0215 inch diameter minimum (nonclosed entry contacts only).
Test pin finish: 16 microinches.
Insertion depth: .050 inch minimum.
Number of insertions: 1.
5
