MIL-PRF-39012/73C
TABLE IV. Category B non-field replaceable (special tools may be required).
NOT FOR ARMY, NAVY, OR AIR FORCE USE. FOR OEM USE ONLY
Dash No. 1/
# Applicable cable group
Typical mating
Dimensions
Inches
from MIL-PRF-39012,
connector
(millimeters)
2/
M39012/73
appendix B
maximum
M17/
3/
B0008 4/ 5/
93-RG178 * @
M39012/74B0008
169-00001 %
M39012/76B0008
B0009 4/ 5/
113-RG316 * @
M39012/74B0009
172-00001 %
M39012/76B0009
119-RG174
173-00001 %
A
1.10 (27.94)
B0010 4/ 5/
94-RG179 * @ ^
M39012/74B0010
M39012/76B0010
B0013 4/
93-RG178 * @
M39012/74B0014
169-00001 %
M39012/76B0014
B0014 4/
113-RG316 * @
M39012/74B0015
172-00001 %
M39012/76B0015
119-RG174
173-00001 %
B0015 4/
94-RG179 ^ @ *
M39012/74B0016
M39012/76B0016
1/
For cross-reference of dash number to superseded PIN or type designation, see table VI.
2/
Mating connector PIN are for reference only. All mating connectors may not be listed.
3/
Dimensions are in inches. Metric equivalents are given for information only.
4/
These connectors have captive center contacts.
5/
Connector bodies shall be gold plated in accordance with ASTM B488, type II, code C, class 1.27.
#
The latest version of each cable shall be applicable.
*
Cable to be used when performing tests requiring cable except as in note @.
@
Cable to be used for the +200°C thermal shock tests.
%
Caution is directed to the application of this cable above 400 MHz. Attenuation is tested only at 400
MHz. SRL and power handling capabilities are not stipulated herein.
^
These are not 50 ohm cables, therefore, when attached to the specified connectors, VSWR, RF
leakage and insertion loss are not applicable.
NOTE: Connectors mate with connectors of the same material only; Example: M39012/73-3001 mates
with M39012/74-3001, and M39012/73-4001 mates with M39012/74-4001.
