MIL-PRF-49142/9D
TABLE I. Dash number and applicable cable Continued.
Cable 2/
Dash number
("X" in the dash number allows
material options, refer to the basic
document) 1/
Category G Use of MIL-DTL-22520 tool required for assembly 3/ 7/ 8/
X013
M17/134-00001
M17/134-00003
X014
M17/134-00002
M17/134-00004
X015
M17/116-RG307
X016
M17/45-RG108
M17/186-00001
X017
M17/176-00002 6/
X018
M17/177-00001 6/
X019
M17/178-00001
X020
M17/179-00001
X021
M24643/33-01UN
X021
X024
M17/135-00003
M17/135-00005
X025
M17/135-00004
M17/135-00006
1/
The "X" is placed in the dash number to allow the user connector body plating
options provided in the general specification. Only connectors of the same
materials are to be intermated to reduce the possibility of dissimilar problems,
including galvanic corrosion.
2/
The latest version of each cable shall be applicable.
3/
These connectors have captivated center contacts.
4/
Not for Navy use. THIS NOTE WILL BE DELETED.
5/
Inactive for new design (see table III).
Cables to be used for the +200°C thermal shock test.
6/
7/
These connectors are assembled using the applicable crimping tool to the
specified cables.
8/
Complete connector assembly shall consist of a body, center contact,
intermediate contact, ferrule, and assembly instructions.
5
