INCH-POUND
MIL-PRF-55339/1B
25 August 2004
SUPERSEDING
MIL-PRF-55339/1A
29 April 1975
PERFORMANCE SPECIFICATION SHEET
ADAPTER, CONNECTOR, COAXIAL, RADIO FREQUENCY, IN-LINE,
(BETWEEN SERIES BNC JACK TO SERIES N JACK), CLASS 2
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall
consist of this specification sheet and MIL-PRF-55339.
NOTES:
1. Dimensions are in inches.
2. This dimension is the largest overall diameter of the adapter.
3. Metric equivalents are given for general information only.
4. Interface dimensions shall be in accordance with MIL-STD-348, series BNC socket contact and
series N socket contact.
FIGURE 1. General configuration.
AMSC N/A
FSC 5935
