MIL-PRF-55339/13B
Vibration, high frequency:
Interruptions: 1 µs, maximum.
Shock: Test condition I.
Thermal shock: Test condition C.
Moisture resistance: 200 megohms, minimum.
Corona level:
Voltage: 375 V, minimum.
Altitude: 70,000 feet (4.437 kPa), minimum.
RF high potential withstanding voltage:
RF voltage: 1,000 Vrms, minimum.
Frequency: 5 MHz, minimum.
Salt spray (corrosion): Applicable.
Coupling mechanism retention force: Not applicable.
Part or Identifying Number (PIN):
M55339/13-00492 Hermetic and M55339/13 -00001 Non-hermetic or:
PIN: M55339/13-70001 Hermetic and M55339/13-70002 Non-hermetic. CAUTION: THIS PART
HAS A NICKEL PLATED BODY AND IS NOT FOR USE IN APPLICATIONS WHERE PASSIVE
INTERMODULATION GENERATION (PIM) MAY BE A CONCERN.
TABLE I. Cross reference of PINs.
PIN
Superseded PIN or type designation 1/
M55339/13-00492
MS35177
REB49098
UG-492D/U
1/
The superseded PIN or the type designation is for cross-reference only.
Where a superseded PIN or type designation is not given; none was
assigned or will be assigned.
Reference documents. In addition to MIL-PRF-55339, this document references the following:
MIL-STD-348
Changes from previous issue. Marginal notations are not used in this revision to identify changes with
respect to the previous issue due to the extent of the changes.
4
