MIL-PRF-55339/14A
Contact resistance (milliohms, maximum).
Initial
After
Contact
Center
2.5
3.0
Outer
0.5
N/A
Outer (-70001)
1.0
N/A
Vibration, high frequency:
Interruptions: 1 µs, maximum.
Shock: Test condition I.
Thermal shock: Test condition C.
Moisture resistance: 200 megohms, minimum.
Corona level:
Voltage: 375 V, minimum.
Altitude: 70,000 feet (4.437 kPa), minimum.
RF high potential withstanding voltage:
RF voltage: 1,000 Vrms. minimum.
Frequency: 5 MHz, minimum.
Salt spray (corrosion): Applicable.
Coupling mechanism retention force: 100 lb (444.82 N), minimum.
Part or Identifying Number (PIN): M55339/14-00306 or:
PIN: M55339/14-70001 CAUTION: THIS PART HAS A NICKEL PLATED BODY AND IS NOT
FOR USE IN APPLICATIONS WHERE PASSIVE INTERMODULATION GENERATION (PIM) MAY
BE A CONCERN.
TABLE I. Cross reference of PINs.
Superseded PIN or type designation 1/
PIN
M55339/14-00306
MS35368
UG-306B/U
1/ The superseded PIN or the type designation is for cross reference
only. Where a superseded PIN or type designation is not given,
none was assigned or will be assigned. PIN: M55339/14-00306
shall be used in all cases for marking and identifying the adapter.
Reference documents. In addition to MIL-PRF-55339, this document references the following:
MIL-STD-348
