MIL-PRF-55339/17B
Reference
Series
Contact
Inches
mm
.593
15.06
A
BNC
Pin
1.093
27.76
1.312
33.32
B and C
BNC
Socket
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. All undimensioned pictorial representations are for reference purposes only.
4. Interfaces to be in accordance with MIL-STD-348, series BNC pin contact and series BNC socket
contact.
FIGURE 1. General configuration - Continued.
